Description

CONVENIENT LAMP CHANGE: The UV lamp can be changed while the unit is running – no need to switch off the filter, no need to dismantle the quartz glass

PROTECTED: The high-quality UVC housing protects the ballast unit from sunlight and moisture

POWERFUL: All latest generation FiltoClear models feature upgraded, highly effective UV lamps

2-WAY VALVE: Choose whether the water flows into the pond or into the waste water after cleaning the filter

IMPROVED EFFICIENCY: The built-in OASE bypass technology ensures optimum water flow and prevents the filter from clogging

STABLE AND ROBUST: The hard-wearing housing made of high-quality plastic can be easily buried in the ground and impresses with its long durability

UNDER PRESSURE: The metal clamping ring with simple lever function makes opening and closing a FiltoClear safer and easier than ever before

Technical Data?

Dimensions (Ã? x H)	mm	380 x 488
Rated voltage		220 – 240 V / 50/60 Hz
Net weight	kg	14.50
Limited Warranty	Years	2 + 1
UVC power	W	24
Number of blue filter foams	Units	1
Number of red filter foams	Units	1
Number of purple filter foams	Units	1
Inlet connections	mm	38 / 50
Inlet connections		1 ?”, 2″
Connections, outlet	mm	38 / 50
Outlet connections		1 ?”, 2″
Connections, sludge discharge	mm	38 / 50
Sludge discharge connections		1 ?”, 2″
Max. flow rate	l/h	9000
Max. operating pressure	bar	0.2
Suitable for ponds up to max.	m³	13.0
Suitable for ponds with fish stock	m³	7.0
Dimensions filter (L x W x H)	mm	380 x 380 x 488
Rated voltage filter		220 – 240 V / 50 – 60 Hz
Power consumption UVC	W	24
UVC cleaning rotor		No
Guarantee (+ request guarantee)	Years	2 + 1
Power cable length UVC	m	5.00
Dimensions pump (L x W x H) ?? mm	mm	340 x 280 x 165
Rated voltage Pump		220 – 240 V / 50 – 60 Hz
Power consumption pump	W	60
Guarantee (+ request guarantee) pump	Years	3 + 2
Power cable length pump	m	10.00
