Description

CONVENIENT LAMP CHANGE: The UV lamp can be changed while the unit is running – no need to switch off the filter, no need to dismantle the quartz glass

PROTECTED: The high-quality UVC housing protects the ballast unit from sunlight and moisture

POWERFUL: All latest generation FiltoClear models feature upgraded, highly effective UV lamps

2-WAY VALVE: Choose whether the water flows into the pond or into the waste water after cleaning the filter

IMPROVED EFFICIENCY: The built-in OASE bypass technology ensures optimum water flow and prevents the filter from clogging

STABLE AND ROBUST: The hard-wearing housing made of high-quality plastic can be easily buried in th
e ground and impresses with its long durability

UNDER PRESSURE: The metal clamping ring with simple lever function makes opening and closing a FiltoClear safer and easier than ever before

Technical Data?

Dimensions (Ã? x H)	mm	380 x 608
Rated voltage		220 – 240 V / 50/60 Hz
Net weight	kg	9.60
Limited Warranty	Years	2 + 1
UVC power	W	42
Number of blue filter foams	Units	2
Number of red filter foams	Units	1
Number of purple filter foams	Units	1
Inlet connections	mm	38 / 50
Inlet connections		1 ?”, 2″
Connections, outlet	mm	38 / 50
Outlet connections		1 ?”, 2″
Connections, sludge discharge	mm	38 / 50
Sludge discharge connections		1 ?”, 2″
Max. flow rate	l/h	13000
Max. operating pressure	bar	0.2
Suitable for ponds up to max.	m³	19.0
Suitable for ponds with fish stock	m³	10.0
Suitable for ponds with koi	m³	5.0
Power consumption UVC	W	42
UVC cleaning rotor		Yes
Power cable length UVC	m	5.00
